1.5ton electric pallet truck，electric pallet Jack，electric forklift
1、the truck is simple and dexterous ,with small turning radius and small weight,it is suitable for ultra-narrow channel operation;
2、the truck has compact and reliable structure,the oil pipeline and line are wrapped in the truck body which is safe and beautiful and convenient for user maintenance;
3、the truck adopt integrated handle design intergrating key switch and electric meter which is simple and comfortable for operation;
4、hand-held lithium battery makes battery changing easier and more convenient;
5、standing configuration of emergency stop switch and emergency reverse device ensure truck safety;
6、the truck is assembled with power-off braking function,the truck is braked as soon as the handle is loosened or pressed to the bottom;
7、electromagnetic is braking and motor braking are used to ensure the safety of driving
|
model |
unit |
EPT15 |
|
power unit |
electric |
|
|
operation |
pedestrian |
|
|
rated traction weight |
t |
1.5 |
|
load centre |
mm |
600 |
|
wheel base |
mm |
1220 |
|
service weight with battery |
kg |
155 |
|
wheels type |
PU |
|
|
driving wheel size |
mm |
φ210*70 |
|
bearing wheel size |
mm |
φ80*70 |
|
wheel ,number front /rear(x=driven) |
1*/4 |
|
|
balance wheel |
yes |
|
|
ground clearance |
mm |
30 |
|
lifting height |
mm |
110 |
|
heihgt of tiller in drive position Min/Max |
mm |
1250 |
|
overall length |
mm |
1540 |
|
overall width |
mm |
560/680 |
|
fork dimensions |
mm |
160*1150/160*1220 |
|
width of fork |
mm |
560/680 |
|
channel width(1000mm*1200mm tray) |
mm |
1500 |
|
min.turning radius |
mm |
1350 |
|
travel speed Laden /unladen |
km/h |
4/5 |
|
maximum climbing ability ,with/without load |
% |
5/7 |
|
service brake |
electromagnetic |
|
|
drive motor ,60minute rating |
w |
750 |
|
lifting motor rating at S3 15% |
w |
Bucher 500 |
|
battery voltage /rated capacity 24V |
Ah |
25ah |
|
charging time |
H |
2.5-3 |
|
working time after full charge |
H |
4 |
|
battery weight (5%) |
kg |
5 |
|
noise level at operator's ear |
dB(A) |
≤70 |
