electric stacker electric forklift electric forklift truck battery forklift the electric stacker can lifting 5000mm

Short Description:

Product name:electric stacker  electric forklift  electric forklift truck  battery forklift

the electric stacker can lifting 5000mm

FOB price is $4500-$4900


Product Detail

Product Tags

Product advantages

1. Emergency reverse device;

2. Straddle leg design,adjustable fork for handling closed pallet;

3. Powerful AC driving motor;

4. The built-in unloading valve protects the stacker from overloading and improves the reliability of the stacker;

5. Emergency power off switch;

6. Turtle-shaped slow speed switch;

7. Infinitely variable speeds control;

8. Foldable, thickened pedals and guard bar,make opera­tor more comfortable and safety;

9. The side cylinder ensures wide field of view operation and stability of the stacker;

10 The balance wheel of the spring adjustment structure is hard-wearing and has good stability.

Product parameter

Model

Unit

CDD-B15

Rated load

Kg

1500

Load center distance

C(mm)

500

Front overhang

X(mm)

960

Wheel tread

Y(mm)

1555

Weight(with battery)

Kg

1150

Wheel material



PU

Front wheel size

(mm)

φ250*80

Rear wheel size

(mm)

φ80*70

Additional wheel size

(mm)

φ100*50

Number of wheels(X=driving wheel)



1X+2/4

Front-wheel track

B10(mm)

886

Rear-wheel track

B11(mm)

525

Lifting height of fork above ground

H3(mm)

5000

Height of the gantry is lowed

H1(mm)

2257

Maximum height of forklift work

H4(mm)

5590

Min. height of fork above ground

H13(mm)

90

Overall length

L1(mm)

2140

Fork size

s/e/l(mm)

60*170*1100

Overall width

B1(mm)

1160

Fork width

B5(mm)

690

Channel width(1000*1200mm tray)

Ast(mm)

2464

Channel width(800*1200mm tray)

Ast(mm)

2401

Radius of turning circle

Wa(mm)

1600

Driving speed, full load/no load

Km/h

4/5.6

Lifting speed, full load/no load

m/s

0.08/0.1

Falling speed, full load/no load

m/s

0.09/0.12

Service brake



Electromagnetic brake

Driving motor power

kw

1.5

Lifting motor power

kw

2.2

Battery 24v

Ah

210

Noise level according to DIN12053

DB(A)

<70

Our packing

Our packing

Why choose us?

1. quality

our products meet CE certificate and other certificate so you can get high quality products from our company

2. price

we are the company which has near 20years experience in this industry,so we can provide the competitive price and high quality product for our customers

3. packing

we can do according to the customer’s requirement

4. transport

usually the products can be shipping by sea

5. service

we offer specialized logistic service including export declaration,customs clearance and every detail during shipment,so that we can make us able to offer you one-step service from order to the products to your hand
